UPW1J271MHD1TN
ALUMINUM ELECTROLYTIC CAPACITOR, 270UF,
Image is for illustrative purposes only. Please refer to product description.
ManufacturerNICHICON
Manufacturer Part NoUPW1J271MHD1TN
Order Code1899881
Product RangeUPW Series
Technical Datasheet
No Longer Stocked
Delivery Charge: €25.00 once per order. 3 business days delivery for in stock items.
Product Information
ManufacturerNICHICON
Manufacturer Part NoUPW1J271MHD1TN
Order Code1899881
Product RangeUPW Series
Technical Datasheet
Capacitance270µF
Voltage(DC)63V
Capacitance Tolerance 20%
Capacitor TerminalsPC Pin
Lifetime @ Temperature8000 hours @ 105C
Capacitor Case / PackageRadial Leaded
Lead Spacing7.5mm
PolarityPolar
Product Diameter16mm
Product Height15mm
Product Width-
ESR0.18ohm
Product RangeUPW Series
Qualification-
Ripple Current1.41A
Operating Temperature Min-55°C
Operating Temperature Max105°C
SVHC6,6'-di-tert-butyl-2,2'-methylenedi-p-cresol
Technical Specifications
Capacitance
270µF
Capacitance Tolerance
20%
Lifetime @ Temperature
8000 hours @ 105C
Lead Spacing
7.5mm
Product Diameter
16mm
Product Width
-
Product Range
UPW Series
Ripple Current
1.41A
Operating Temperature Max
105°C
Voltage(DC)
63V
Capacitor Terminals
PC Pin
Capacitor Case / Package
Radial Leaded
Polarity
Polar
Product Height
15mm
ESR
0.18ohm
Qualification
-
Operating Temperature Min
-55°C
SVHC
6,6'-di-tert-butyl-2,2'-methylenedi-p-cresol
Technical Docs (1)
Associated Products
2 Products Found
Legislation and Environmental
Country of Origin:
Country in which last significant manufacturing process was carried outCountry of Origin:Japan
Country in which last significant manufacturing process was carried out
Country in which last significant manufacturing process was carried outCountry of Origin:Japan
Country in which last significant manufacturing process was carried out
Tariff No:85322200
RoHS Compliant:Yes
RoHS
RoHS Phthalates Compliant:To be advised
SVHC:6,6'-di-tert-butyl-2,2'-methylenedi-p-cresol
Download Product Compliance Certificate
Product Compliance Certificate
Weight (kg):.00135
